MQS-AP Seismic rod hinge

Hinge MT-S-AP-10 #2330875

PLM_Hilti_Installation-Playbook_Seismic-full_1080p-47pr__EN (EN / 228303)

Galvanised threaded rod hinge for seismic bracing of MEP support structures

Diameter - D: 11.6 mm
Material composition: Base plate: S355MC - DIN EN 10149-2, Pin: 11SMn30+C - DIN EN 10277-3, Threaded washer: 11SMn30+C - DIN EN 10277-3, Hexagon screws: Steel grade 8.8, Washer: Galvanised steel
Surface finish: Indoor Coated - Electro galvanised

Choose options

Diameter - D

11.6 mm

Pack size

10 pc

Product options

Quantity

Total Pieces

You can not see your company prices

Please Log in or register to see your company prices.

Discounted net

2.450.000,00 VND

245.000,00 VND / 1

Technical Data

Diameter - D

11.6 mm

Material composition

Base plate: S355MC - DIN EN 10149-2, Pin: 11SMn30+C - DIN EN 10277-3, Threaded washer: 11SMn30+C - DIN EN 10277-3, Hexagon screws: Steel grade 8.8, Washer: Galvanised steel

Surface finish

Indoor Coated - Electro galvanised

Material thickness

6 mm

Environmental conditions

Dry indoor conditions (C1) Indoor with temporary condensation (C2)

Weight

179 g

Documents

Features & Applications

Features

Rapid installation – helps to save time on-site thanks to single-anchor fastening: all you need is the single pre-assembled screw and no additional nuts
High load capacity – designed for optimal seismic load transfer to the support
Versatile – load range suitable for a wide range of light- and medium-duty MEP installations
Engineering support available – contact your local Hilti team for project-specific advice
Bracing pre-assembly possible – providing additional productivity in seismic support installation

Applications

Installing pipes, cable trays and air duct supports in seismic-relevant areas
Fastening threaded rod seismic bracing to concrete or connecting to MQS-W seismic angles
Recommended for use in dry, interior environments
